100k Volume Control Connection

72 / 100

100k volume control connection

Hi Friends Today in This Article We Going To See Volume Control Connection Details

What is volume control?
Volume Control is nothing but its variable resistor It Will Control Your Volume To Raise And Reduce
according To Your desire.

List Of Volume Controls

Volume Controls Comes With Two Types

  1. Stereo Control
  2. Mono Control
  1. Stereo Volume Control
100k volume control connection

Like Above Picture L And R Input Is Audio Left And Right Channel Audio Input
L And R Output Is Audio Left And Right Audio Output
Ground To be Both Left and Right Audio Ground.

2. Mono Volume Control


Mono Controls Mainly Used for Single-channel Audio Volume Controller.
It’s mainly used for the 5.1 amplifier subwoofer and center channel Volume Control.
